AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
* Refer to www.asus.com for CPU support list.
ערכת שבבים
AMD B650
זיכרון
4x DIMM, Max. 128GB, DDR5
6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports AMD EXTended Profiles for Overclocking (EXPO™)
OptiMem II
* Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
** Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function
גרפיקה
1x DisplayPort*
1x HDMI® port**
* Supports max. 8K@60Hz as specified in DisplayPort 1.4.
** Supports 4K@60Hz as specified in HDMI 2.1.
*** VGA resolution support depends on processors’ or graphic cards’ resolution.
חריצי הרחבה
AMD Ryzen™ 7000 Series Desktop Processors*
1x PCIe 4.0/3.0 x16 slot AMD B650 Chipset
1x PCIe 4.0/3.0 x16 slot (supports x4 mode)
1x PCIe 4.0/3.0 x1 slot
* Please check PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/).
אחסון
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
AMD Ryzen™ 7000 Series Desktop Processors
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) AMD B650 Chipset
4x SATA 6Gb/s ports
* AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
רשת
1x Realtek 2.5Gb Ethernet
TUF LANGuard
תקשורת אלחוטית
–
USB
Rear USB (Total 8 ports)
1x USB 3.2 Gen 2×2 port (1x USB Type-C®)
2x USB 3.2 Gen 2 ports (2x Type-A)
1x USB 3.2 Gen 1 port (1x Type-A)
4x USB 2.0 ports (4x Type-A) Front USB (Total 7 ports)
1x USB 3.2 Gen 1 connector (supports USB Type-C®)
1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2x USB 2.0 headers support additional 4 USB 2.0 ports
שמע
Realtek 7.1 Surround Sound High Definition Audio CODEC
– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
– Supports up to 24-Bit/192 kHz playback Audio Features
– Audio Shielding
– Premium audio capacitors
– Dedicated audio PCB layers
חיבורים ויציאות
1x USB 3.2 Gen 2×2 port (1x USB Type-C®)
2x USB 3.2 Gen 2 ports (2x Type-A)
1x USB 3.2 Gen 1 port (1x Type-A)
4x USB 2.0 ports (4x Type-A)
1x DisplayPort
1x HDMI®port
1x Realtek 2.5Gb Ethernet port
5x Audio jacks
1x BIOS FlashBack™ button
חיבורים פנימיים
Fan and Cooling related
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x 4-pin AIO Pump header
3x 4-pin Chassis Fan headers Power related
1x 24-pin Main Power connector
1x 8-pin +12V Power connector
1x 4-pin +12V Power connector Storage related
2x M.2 slots (Key M)
4x SATA 6Gb/s ports USB
1x USB Gen 1 connector (supports USB Type-C® )
1x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous
3x Addressable Gen 2 headers
1x Aura RGB header
1x Clear CMOS header
1x COM Port header
1x Front Panel Audio header (AAFP)
1x 20-3 pin System Panel header with Chassis intrude function
1x Thunderbolt™ (USB4®) header
תכונות מיוחדות
ASUS TUF PROTECTION
– DIGI+ VRM (- Digital power design with DrMOS)
– Enhanced DRAM Overcurrent Protection
– ESD Guards
– TUF LANGuard
– Overvoltage Protection
– SafeSlot Core+
– Stainless-Steel Back I/O ASUS Q-Design
– M.2 Q-Latch
– Q-DIMM
– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
– Q-Slot ASUS Thermal Solution
– M.2 heatsink
– VRM heatsink design ASUS EZ DIY
– BIOS FlashBack™ button
– BIOS FlashBack™ LED
– ProCool
– Pre-mounted I/O shield
– SafeDIMM Aura Sync
– Aura RGB header
– Addressable Gen 2 headers
תכונות תוכנה
ASUS Exclusive Software
Armoury Crate
– Aura Creator
– Aura Sync
– Fan Xpert 2+
– Power Saving
– Two-Way AI Noise Cancellation
AI Suite 3
-TurboV EVO
-DIGI+ VRM
-PC Cleaner
TUF GAMING CPU-Z
DTS Audio Processing
Norton Anti-virus software (Free Trialversion)
WinRAR UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode
BIOS
256 Mb Flash ROM, UEFI AMI BIOS
ניהוליות
WOL by PME, PXE
מערכות הפעלה תומכות
Windows® 11, Windows® 10 64-bit
תצורה
mATX Form Factor
9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
